DS Servo DS5160 Digital 70KG/0.13sec8.4V

Write a review
CHF 29.90
Including tax
Available immediate delivery: 2 pcs.
+ −
Add to comparison list Add to wish list Rate this product
DS023

Further products by DS Servo >

  • Order by 4 PM, delivered tomorrow! (stock items)
  • 30 years of RC model building experience
  • Top service by professional model builders
  • Over 500 manufacturers - 200,000 products

DS Servo DS5160 Digital 70KG/0.13sec8.4V

Eigenschaften:

Extrem hohe Stellkraft - bis zu 70kgcm bei 8.4V

3-Pol-Motor im robusten Aluminiumgehäuse

Großes Servoformat für Heavy-Duty Anwendungen

Staub- & wasserdicht nach IP67

270° Steuerwinkel möglich

Doppelte Kugellager und präzises 3µsec Deadband

Ideal für 1/5 Modelle oder große Crawler

Technische Spezifikationen:

Spannung:6.0V7.4V8.4V

Stellgeschwindigkeit:0.17 sec/60°0.15 sec/60°0.13 sec/60°

Drehmoment (Stall):58 kgcm65 kgcm70 kgcm

Motor:3-Pol

Getriebeübersetzung:279

Art:Digital (PWM)

Ansteuerfrequenz:50–330Hz

Kugellager:Doppelt

Abmessungen:65 × 30 × 48mm

Gewicht:158.0g

Winkelbereich:180° oder 270° (500–2500µs)

Wasserdicht:IP67

Positioning time sec.:
  • 0.13
Manufacturer:
DS Servo

Battery

Application:
  • Hobby Einsteiger
Width mm approx.:
  • 48
Height mm approx.:
  • 30
Weight g approx.:
  • 158

Chargers

Max. Input voltage:
  • 8.4 Volt
Housing material:
Kunstoff / Metall

Motors electric

Motor type:
Brushless

Tires

Modulation:
Digital

Remote control

Scope of application:
  • Fahrzeuge
  • Flugmodelle
  • Boote / Schiffe

Servos

Housing size:
  • Standard Servo
Positioning force kg:
  • 70
Transmission:
Metall

Servo horns

Length mm approx.:
  • 65

Battery connector

Plug:
  • JR Uniplug

Tool

Waterproof:
Ja
Servo horn recording:
25 Zähne (Futaba - Savöx - Traxxas usw.) 25T
