Yeah Racing IP67 40KG Waterproof HV Torque Servo

Write a review
CHF 99.90
Including tax
Not in stock at the supplier. Delivery date unknown. (Delivery time 4-12 weeks)
+
YE-0036BK

Further products by Yeah Racing >

  • Order by 4 PM, delivered tomorrow! (stock items)
  • 30 years of RC model building experience
  • Top service by professional model builders
  • Over 500 manufacturers - 200,000 products
YE-0036BK Yeah Racing IP67 40KG Waterproof HV High Torque Aluminum Case Brushless Digital Servo For 1/8 1/10 Crawler Buggy Off-road

Yeah Racing's newest high torque water proof servo, with an aluminum front and middle section to help dissipate the heat! Featuring a IP67 waterproof rating, meaning it will be more than enough to tackle depths of water during crawling on trails!


Specification:

Torque: 7.4V: 38kg-cm (528 oz-in), 8.4V: 40kg-cm (556 oz-in)

Speed: 7.4V: 0.078sec/60deg. , 8.4V: 0.065sec/60deg.

Connector Wire Length: 11.8 in. / 300 mm

Connector Wire Gauge: 25 AWG Black Wire

Gear: Titanium Gears + Copper Gears

Size: 40 x 20 x 38mm (1.57 x 0.79x 1.50in)

Weight: 79g (2.19oz)

Servo Spline 25T

Akku

Application:
  • Hobby Racer / Basher
  • Competition Wettbewerb
Width mm approx.:
  • 40
Height mm approx.:
  • 20
Weight g approx.:
  • 79

Ladegeräte

Max. Input voltage:
  • 8.4 Volt
Housing material:
Kunstoff / Metall

Motoren Elektro

Motor type:
Brushless

Reifen

Modulation:
Digital

Felgen

Color:
  • Schwarz

Fernsteuerung

Scope of application:
  • Fahrzeuge
  • Boote / Schiffe

Servos

Housing size:
  • Standard Servo
Positioning force kg:
  • 40
Transmission:
Metall

Servohörner

Length mm approx.:
  • 38

Akkustecker

Plug:
  • JR Uniplug

Werkzeug

Waterproof:
Ja
Servo horn recording:
25 Zähne (Futaba - Savöx - Traxxas usw.) 25T

No reviews found
